Oписание продукта

MS7221 DC 0-10V 0-24mA Multifunction Process Calibrator with Voltage Current signal generator

HTB1cXGKNpXXXXXjapXXq6xXFXXXG

Introductioan:
MS7221 Volt/mA Calibrator is a source and measurement tool. This Calibrator is use to measure or output 0 to 24 mA DC current loop, and 0 to 10 V DC voltage. But the calibrator cannot be used to measurement and source simultaneously.

Overview:
Maximum voltage applied between any jack and earth ground or any tow jack: 30V
Storage temperature: -40℃ to 60℃
Operating temperature: -10℃ to 55℃
Operating altitude: 3000 meters maximum
Temperature coefficient: +-0.005% of range per ℃ for the temperature range -10℃ to 18℃ and 28℃ to 55℃
Relative humidity: 95% up to 30℃, 75% up to 40℃, 45%up to 50℃, 35% up to 55℃
Shock: Random 2g, 5Hz to 500Hz
Safety: 1 meter drop test
Power requirement: 9VDC, 006P or 1604A
Size: 190mm(L) x 89mm(W) x 42mm(H)
Weight: 350g (include battery)
Auto Power off: 6 min
Cancel the function of Auto Power Off: Hold Input / Output key, then press Power button. The full screen appears and the Auto Power Off is canceled. On the contrary, the Auto Power Off could be recovered after reboot the calibrator.
Safety rating: CE(EMC) RoHS

Main Features
Storage Temperature: -40 ℃~60 ℃
Operating Temperature: -10 ℃~55 ℃
Operating Altitude: 3000 meters maximum
Temperature Coefficient: ±0.005% of range per  ℃ for the TEMP range -10~18 ℃ and 28~55 ℃
Relative Humidity:
95% up to 30℃  75% up to 40℃
45% up to 50℃  35% up to 55℃
Shock: Random 2g   5Hz~500Hz
Low Battery Display

HTB1WdDhNpXXXXb9XXXXq6xXFXXX9

SpecificationRangeResolutionAccuracy


DC V mV Input 0~100mV 0.01mV
0~10V 0.001V
DC V mV Output 0~100mV 0.01mV
0~10V 0.001V
Loop Power Output 24V DC N/A
DC mA Input 0~24 mA 0.001mA
DC mA Output 0~24 mA 0.001mA
DC V Input and Output 100mV 0.01mV +/-(0.02%+2)
10V 0.001V +/-(0.02%+2)
DC mA Input and Output 24mA 0.001mA +/-(0.015%+5)
Loop Power  24V   +/-10%

Package Contents

1 x Mastech MS7221 Meter
2 x Test Leads
1 x Carrying Case
1 x User Manual

HTB1puy_NpXXXXXQXFXXq6xXFXXXW

HTB1GDi6NpXXXXa1XFXXq6xXFXXXR
